87" High x 24' Long Super Steel Portable Windbreak Panel.

Frame is built of 2-7/8" oil pipe., with 1-full pipe top and bottom and 4- vertical pipe.

Ground pipe is 2-7/8" x 10' oil pipe.

Super steel used is 2-24' long sheets.

We use self-cutting 1-1/2' long screws with a 1-1/2' fender washer ender each screw to help prevent self- cutting screw head from pulling through super steel.

We weld 3-/16" x 2-1/2" x 2-1/2" angle iron on pipe frame and over the ends of super steel.

The angle iron is to prevent cutting of livestock and livestock rubbing against the ends and bending the sheet.

We pinch formed lip of the bottom super steel sheet behind the bottom pipe to prevent livestock from getting a leg between the pipe and super steel.

The lift bar on top of the windbreak panel is made of 2-7/8" oil pipe, it is 7" tall and 108' long

panels can be attached together with the formed panel chain clamps welded to the panel and the 3/16" x 36" chains near the top and bottom of the panel.
